3-WAY CONTROL VALVES M3F-I - DN150

APPLICATIONS


Control valves type M3F-I are designed for regulating of water, lubricating
oil and other liquid media and can be mounted in the pipe system as either
mixing or diverting valves. The valves are used in conjunction with our
temperature regulators for controlling industrial processes, district and
central heating plants and marine installations.

GENERALLY
Sizes: DN150
Nom. pressure: PN10
Material: Cast iron
Material (components): Aluminum bronze
Flanges EN 1092-2

DOWNLOADS
Data sheet: 2.3.12
Data sheet spare part: S-2.3.12
Instruction: 99.22.01
Dimension drawing: 2.3.12- Dimension
3D file: 3d file
Image: Image PNG
